Load Cell
Single Shear Beam Load Cells
Capacity: 100kg - 5,000kg Material: Alloy Steel or Stainless Steel. High accuracy, very good quality and low costs. Laser Sealed, waterproof to IP68 and Anti corrosion. APPLICATIONS: Floor scales, platform scales, weigh bridge and other weighing devices.
Single Point Load Cells
Capacity: 50kg - 500kg. Features: Alloy Aluminum material, good quality, high accuracy and low costs Silicon adhesive sealed, surface anodized. APPLICATIONS: Bench scales, platform scales and other electronic weighing devices.
Bending Beam Load Cells
The bending beam load cell BBF is welded and built in stainless steel, has a thermal seal and has been designed for weighing tanks, hoppers, belts, platforms, single-cell systems, suspended loads and automatic packaging machines. The BBF cell is supplied with a 4-m shielded cable 3 m long.
Tension and Compression (S beam Load Cells)
Capacity: 500Kg - 10,000Kg Features: S shape Load Cell, High Capacity range from 500KG to 10.000KG Alloy Steel Structure, Good performance, High accuracy and low costs, Laser Sealed, Water Proof to IP67. Applications: Crane scale, hopper scale and other electronic weighing test.
Double Shear Beam Load Cell (Cup & Ball Type)
Capacity range from 10Ton to 50Ton. Material: Alloy Steel, good quality, High accuracy and low costs, Glue sealed ,oil-proof, waterproof and anti-corrosion Application: Weigh Bridge, Truck Scale, Weighing Equipment etc
Column, Compression, Canister Load Cell
CAPACITY: 10 TON to 40 TON. High Accuracy and more Stable. Alloy Steel or Stainless-Steel Structure. Laser Sealed, Waterproof to IP67. APPLICATIONS: Suit for Truck Scale, Weigh Bridge and other electronic weighing equipment
A load cell is a transducer that converts force or load into an electrical signal. It is typically used to measure weight or force in various applications. Load cells operate on the principle of strain gauges, which change resistance when subjected to force. This change in resistance is then converted into an electrical signal, providing an accurate measurement of the applied load.
There are several types of load cells, each designed for specific applications. Common types include:
Compression Load Cells: Designed to measure compressive forces, typically used in applications where a load is applied from above.
Tension Load Cells: Used to measure forces in tension, commonly employed in applications where the load is suspended from the load cell.
Shear Beam Load Cells: These are versatile load cells used in both tension and compression applications, providing accurate measurements in multiple directions.
S-Beam Load Cells: Resemble the letter ‘S’ in shape and are suitable for a wide range of applications, offering good accuracy and repeatability.
Pancake Load Cells: Designed to handle heavy loads, often used in industrial and construction applications.
Selecting the right load cell involves considering factors such as the type of force being measured (compression, tension, etc.), the expected range of loads, environmental conditions (e.g., temperature, humidity), and the required accuracy. It’s also important to ensure compatibility with the equipment or system it will be integrated into. Consulting with a load cell manufacturer or supplier with expertise in your industry can help in making the appropriate selection.
